| Basic performance parameters | |
| Machine working weight (kg) | 2371.5 |
| Bucket capacity (m³) | 0.054 |
| Travel speed low/high speed (Km/h) | 0-1.5/0-2.8 |
| Gradeability(%) | 30% |
| Ground pressure (Kpa) | 33.4 |
| Maximum digging force (kN) | 18.4 |
| Maximum digging radius (mm) | 4143 |
| Maximum digging depth (mm) | 2293 |
| Maximum digging height (mm) | 3761 |
| Maximum unloading height (mm) | 2496 |
| Maximum deflection angle (°) | 125 |
| Track extension range (mm) | 1300-1500 |
| Engine | |
| Engine brand | Kubota |
| Engine model | D1105 |
| Maximum horsepower (ps) | 24.75 |
| Maximum power (Kw) | 18.2 |
| Maximum speed (rpm) | 3000 |
| Displacement (L) | 1.123 |
| Number of cylinders | 3 |
| Cooling method | Water-cooled |
| Engine oil change amount (L) | 4.2 |
| Fuel form | DIESEL |
| Fuel grade | 0/-10 |
| Theoretical fuel consumption (L/h) | 1.3-1.5 |
| Body | |
| Transport length (mm) | 2824 |
| Transport width (mm) | 1300 |
| Transport height (mm) | 2361 |
| Counterweight ground clearance(mm) | 510 |
| Bucket width (mm) | 450 |
| Boom length (mm) | 1830 |
| Arm length (mm) | 1250 |
| Bulldozer blade width (mm) | 1300 |
