| Basic performance parameters | |
| Machine working weight (kg) | 3171 |
| Bucket capacity (m³) | 0.08 |
| Travel speed low/high speed (Km/h) | 0-1.8/0-2.8 |
| Gradeability(%) | 30% |
| Ground pressure (Kpa) | 36 |
| Maximum digging force (kN) | 27 |
| Maximum digging radius (mm) | 4831 |
| Maximum digging depth (mm) | 2827 |
| Maximum digging height (mm) | 4563 |
| Maximum unloading height (mm) | 3181 |
| Maximum deflection angle (°) | 110 |
| Track extension range (mm) | – |
| Engine | |
| Engine brand | Kubota |
| Engine model | V1505 |
| Maximum horsepower (ps) | 25 |
| Maximum power (Kw) | 18.5 |
| Maximum speed (rpm) | 2300 |
| Displacement (L) | 1.5 |
| Number of cylinders | 4 |
| Cooling method | Water-cooled |
| Engine oil change amount (L) | 6 |
| Fuel form | Diesel |
| Fuel grade | 0/-10 |
| Theoretical fuel consumption (L/h) | 1.3-1.5 |
| Body | |
| Transport length (mm) | 2824 |
| Transport width (mm) | 1300 |
| Transport height (mm) | 2361 |
| Counterweight ground clearance(mm) | 510 |
| Bucket width (mm) | 450 |
| Boom length (mm) | 1830 |
| Arm length (mm) | 1250 |
| Bulldozer blade width (mm) | 1300 |
